| Supply Voltage | 100 to 270 V AC/DC, 50/60 Hz |
| Mounting Type | DIN Rail |
| Model No | EFR-35 |
| Type of Product | Earth Fault Relay |
Supply Voltage |
100 to 270 V AC/DC, 50/60 Hz |
Mounting Type |
DIN Rail |
Model No |
EFR-35 |
Type of Product |
Earth Fault Relay |
Display |
Upper: 3 digit, 7 segment, 0.4 inch (10.16 mm) (White), Lower: 3 digit, 7 segment, 0.28 inch (7.11 mm) (Green) |
Size |
90 X 35 X 63 mm |
Relay |
2 |
Power Consumption |
3 VA @ 230 V AC MAX |
Country of Origin |
India |
Operating Temperature |
0°C to 55°C |
Name of Manufacturer/Packer/Importer |
AP Enterprise |
Input Current |
5 A. AC From CBCT OR CT |
Rating |
5 A, 250 V AC / 30 V DC |
Relay Type |
NO-C-NC, NO-C |
Range |
10% to 100% |
Resolution |
0.01 |
Key |
SET, INC, DEC / RST |
Relative Humidity |
UP to 95% RH (non-condensing) |
