| Tolerance | ±20% |
| Type of Product | Polymer Capacitor |
| Voltage | 10 V DC |
| Mounting Type | Surface Mount |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Tolerance |
±20% |
Type of Product |
Polymer Capacitor |
Voltage |
10 V DC |
Mounting Type |
Surface Mount |
Dissipation Factor |
0.06 |
Country of Origin |
Czech Republic |
Height |
2.9 mm |
Capacitance |
220 µF |
Length |
7.3 mm |
Leakage Current |
220 µA |
Technology |
Polymer |
Maximum Operating Temperature |
+125°C |
Series |
TCQ |
Minimum Operating Temperature |
-55°C |
Dimension |
7.3x4.3x2.9 mm |
Package / Case |
2917 (7343-31) |
Dielectric Material Family |
Tantalum |
Depth |
4.3 mm |
Pack of |
2 Pcs |
Name of Manufacturer/Packer/Importer |
KYOCERA AVX |
Equivalent Series Resistance |
25 mΩ |
Electrolyte Type |
Solid |
Polarised |
Polar |
Automotive Standard |
AEC-Q200 |
Lead Pitch |
4.4 mm |
Manufacturer Part Number |
TCQD227M010R0025E |
Product Code |
1864721 |
