| Tolerance | ±20% |
| Model No | EEUED2C151S |
| Type of Product | Capacitor |
| Voltage | 160 DC |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Tolerance |
±20% |
Model No |
EEUED2C151S |
Type of Product |
Capacitor |
Voltage |
160 DC |
Country of Origin |
Japan |
Capacitance |
150 μF |
Technology |
Aluminum Electrolytic |
Maximum Operating Temperature |
105 |
Minimum Operating Temperature |
-25 |
Pack of |
5 Pcs |
Name of Manufacturer/Packer/Importer |
Panasonic Corporation |
Lead Spacing |
7.5 mm |
Height (mm) |
20 |
Monotaro ID |
65244797 |
Diameter (Φmm) |
18 |
Dimension (mm) |
18(Dia.)x20 |
Surface Mount Device |
Radial, Through Hole |
Specifications |
ED Series. Panasonic ED Series Type A electrolytic capacitors boast a long life of 8000 to 10000 hours (depending on case size) at +105°C. These radial capacitors deliver high frequency and high ripple current. A low profile option with a height of 20 mm is available. Applications. Panasonic ED Series Type V radial capacitors are suitable for power input circuits and electronic ballast applications. |
RoHS Directive |
Correspondence |
Import Country |
Direct Import from Japan |
