| Tolerance | ±20% |
| Model No | 7111198P |
| Type of Product | Electrolytic Capacitor |
| Voltage | 25 V DC |
Tolerance |
±20% |
Model No |
7111198P |
Type of Product |
Electrolytic Capacitor |
Voltage |
25 V DC |
Mounting Type |
Radial, Through Hole |
Polarity |
Polar |
Dissipation Factor |
0.14000000000000001 |
Life Expectancy |
2000 h |
Country of Origin |
Taiwan |
Pitch |
7.5 mm |
ripple current (A) |
1.8 A |
Height |
31 mm |
Capacitance |
4700 µF |
Length |
31 mm |
Leakage Current |
<=0.01 CV or 3 µA at 1 min |
Technology |
Aluminium Electrolytic |
Maximum Operating Temperature |
105°C |
Series |
RS |
Minimum Operating Temperature |
-40°C |
Dimension |
16 (Dia.)x31 mm |
Diameter |
16 mm |
Name of Manufacturer/Packer/Importer |
RS Component |
