| Type of Product | CPLD |
| Dimension | 22x22 mm |
| Length | 22 mm |
| Width | 22 mm |
Type of Product |
CPLD |
Dimension |
22x22 mm |
Length |
22 mm |
Width |
22 mm |
Country of Origin |
United Kingdom |
Maximum Operating Temperature |
+85°C |
Mounting Type |
Surface Mount |
Minimum Operating Temperature |
0°C |
Pin Count |
144 |
Package Type |
TQFP |
Name of Manufacturer/Packer/Importer |
Altera |
Maximum Operating Supply Voltage |
1.89 V |
Minimum Operating Supply Voltage |
1.71 V |
Product Code |
8303647 |
Manufacturer Part Number |
5M240ZT144C5N |
Family Name |
mAX V |
No. of Logic Blocks |
240 |
Memory Type |
Flash |
Re-Programmability Support |
Yes |
In System Programmability |
In System |
Individual Output Enable Control |
Yes |
Number of Macro Cells |
192 |
Number of Users |
114 |
Propagation Delay |
17.7ns |
Propagation Delay Test Condition |
10pF |
