| Type of Product | I/O Module |
| Model No | CPS-MG341G5-ADSC1-931 |
| Series | CONPROSYS IoT Gateway |
| Input Power | (Built-in) 12 V DC |
Type of Product |
I/O Module |
Model No |
CPS-MG341G5-ADSC1-931 |
Series |
CONPROSYS IoT Gateway |
Input Power |
(Built-in) 12 V DC |
Resolution |
(ADC)12-bit |
No. of Channels |
2-ch, 1x RS-232C [asynchronous]; 1x RS-422A/485 [asynchronous] |
Monotaro ID |
66000308 |
Country of Origin |
Japan |
Number of Input Points |
4 points |
Import Country |
Direct Import from Japan |
No. Of Output |
2 points |
Name of Manufacturer/Packer/Importer |
Contec Co., Ltd. |
Transmission Speed |
300 to 115，200bps |
Communication Ports |
Ethernet (LAN); 4G LTE wireless (WAN) |
Input Range |
0 to 20mA |
Transmission Method |
RS-232C [asynchronous]; RS-422A/485 [asynchronous] |
Operating voltage (V) |
12 to 24 DC |
Insulation |
Dielectric withstand surge: - |
Circuit (input) |
Photocoupler isolated input (supports both sink and source output) |
Response Speed |
200 μsec (max.), 2msec (max.), 1KHz |
Counting Mechanism |
24-bit up |
RoHS Directive |
Correspondence |
Programming |
CONPROSYS VTC |
Communication Function |
Https Data Transmission; CNC Link; FacilityView Data Transmission; Modbus Master; Modbus Slave; MTConnect Adapter/Agent; OPC UA Server; PLC Link; BACnet Server; BACnet Client |
