| Cable Type | Wire |
| Insulation Material | PTFE |
| Conductor Material | Silver Plated Copper |
| No of Core | Single Core |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Cable Type |
Wire |
Insulation Material |
PTFE |
Conductor Material |
Silver Plated Copper |
No of Core |
Single Core |
Series |
Hook-up Wire TEFLON |
No. of Strands |
19 |
Color |
White |
Nominal Area |
1.23 mm² |
Type of Product |
Hook Up Wire |
Model No |
5858 WH005 |
Cable Length |
30 m |
Voltage Rating |
600 V |
Standard Met |
MIL-W-16878/4, NEMA HP-EXBBB, UL1213, VW-1 |
Outer Diameter |
2.03 mm |
Country of Origin |
United States |
Wall Thickness |
0.3 mm |
Wire Gauge |
16 AWG |
Maximum Operating Temperature |
+200°C |
Minimum Operating Temperature |
-60°C |
Strands |
0.29 mm |
Resistant To |
and Chemicals, Oils, Solvents |
Outer Sheath material |
PTFE |
Hook Up Wire Type |
High Temperature |
Wire Style |
UL1213 |
Shield Type |
Unshielded |
Name of Manufacturer/Packer/Importer |
RS Components & Controls (I) Ltd |
Core Strands |
19/0.29 mm |
