Insulation Material | Silicone |
Conductor Material | Copper |
No of Core | - |
Series | SIFF |
Insulation Material |
Silicone |
Conductor Material |
Copper |
No of Core |
- |
Series |
SIFF |
No. of Strands |
516 |
Nominal Area |
- |
Type of Product |
Hook Up Wire |
Length |
100 m |
Cable Length |
- |
Voltage Rating |
1.5 kV |
Outer Diameter |
3.7 mm |
Country of Origin |
Ger mAny |
Wall Thickness |
1.1 mm |
Maximum Operating Temperature |
+180°C |
Minimum Operating Temperature |
-50°C |
Name of Manufacturer/Packer/Importer |
Hew Heinz Eilentropp |
Core Strands |
516/0.05 mm |
Manufacturer Part Number |
13433-03-100 |
Product Code |
2225510 |
Cross Sectional Area |
1.1 mm² |
Size of Strands |
0.05 mm |
Sheath Colour |
Red |
Cable Shape |
Single Core |
American Wire Gauge |
17 AWG |
