Ships within 5 days
View
View
View
View
| Type of Product | Function Generator |
| Amplitude | Not less than 50Vpp (open circuit) |
| Accuracy | Less than 0. 003% ±1digit |
| Dimension | 270 x 225 x 90mm. |
Type of Product |
Function Generator |
Amplitude |
Not less than 50Vpp (open circuit) |
Accuracy |
Less than 0. 003% ±1digit |
Dimension |
270 x 225 x 90mm. |
Frequency Range (Hz) |
1Hz ~ 10MHz ³10Vp-p |
Model No |
KM 2005 |
Measurement Range |
1Hz ~ 10MHz ³10Vp-p |
Output Impedance |
50W ± 10% |
Distortion |
Less than 1% at 10H - 100KHz |
Line Power |
220V/110V±10% 50Hz/60Hz |
Weight |
About 2. 5Kg |
Voltage (Dc) |
0 ~ ±10V continuously adjustable |
Symmetry Range |
90:10-- 10:90 |
Frequency |
0.1Hz ~ 5MHz |
Input Impedance |
Not less than 1MW / 20F |
Sensitivity |
100mVrms |
