| Type of Product | DDS Function Generator |
| Amplitude | 1m Vpp - 12.5 Vpp (50Ω), 1m Vpp - 25 Vpp (High Impedance) |
| Display | 4 inch (101.6 mm) high-resolution (480×320 pixels) TFT LCD display |
| Model No | DDS-1005 |
Type of Product |
DDS Function Generator |
Amplitude |
1m Vpp - 12.5 Vpp (50Ω), 1m Vpp - 25 Vpp (High Impedance) |
Display |
4 inch (101.6 mm) high-resolution (480×320 pixels) TFT LCD display |
Model No |
DDS-1005 |
Channel |
Single + Trigger |
Country of Origin |
India |
Resolution |
1m Vpp, or 4 digits |
Output Frequency |
5 MHz |
Sampling time |
125 MS/s |
Name of Manufacturer/Packer/Importer |
Rameshtha Enterprises |
Vertical Resolution |
14 bits |
DC Offset Range (AD+DC) |
±6.25 V (50Ω), ±12.5V (High Impedance) |
DC Offset Range Resolution |
1 mV or 4 digits |
Load impedance |
50 Ω (Typica |
Standard Waveform |
Sine, Square, Pulse, Ramp and Noise |
Wave Length |
2 pts to 8K pts |
Non-Volatile Memory |
64 M Bytes |
