| Country of Origin | India |
| Response Time | <60 second |
| Display Type | With Display, without Display |
| Sensor Type | Electrochemical Sensor |
Country of Origin |
India |
Response Time |
<60 second |
Display Type |
With Display, without Display |
Sensor Type |
Electrochemical Sensor |
Output |
4-20 mA/ 0-10 VDC |
Power Supply |
24 VDC, 200 mA |
Measuring Parameter |
Carbon monoxide (CO) |
Display |
4¹/2 digit LCD display |
Storage Temperature |
-10 to +60 °C |
Type of Product |
Carbon Monoxide Transmitter |
Range |
0-100 ppm, 0-250 ppm |
Accuracy |
±5% in 0~100 ppm range ±10% in 100~250 ppm range |
Dimension |
125 x 80 x 30 mm |
Model No |
AI-CO |
Name of Manufacturer/Packer/Importer |
INSTRUKART HOLDING |
Enclosure |
ABS plastic wall mounting enclosure |
Modbus |
Communication Optional RS-485 Modbus communication |
Coverage Area |
Radius: 15 m Area: 700 m2 (There shall be no obstructions that impacts natural circulation of air such as walls, elevators, stairs etc.) |
Output Type |
Select 0-10 VDC & 4-20 mA, 0-10 VDC & 4-20 mA & RS485, With 4-20 mA Output + Relay |
buzzer |
Optional programmable in built buzzer alarm |
Relay |
Optional single relay output (NO/CO/NC) Freely programmable Rated 2 amps |
