| Country of Origin | India |
| Response Time | T90 (90% of reading) within 60 seconds |
| Output | 4–20 mA / 0–10 VDC output (field selectable) |
| Power Supply | 24 VDC, 250 mA |
Country of Origin |
India |
Response Time |
T90 (90% of reading) within 60 seconds |
Output |
4–20 mA / 0–10 VDC output (field selectable) |
Power Supply |
24 VDC, 250 mA |
Type of Product |
Duct Mounting Carbon Monoxide Transmitter |
Accuracy |
±5 ppm or ±5% of reading, whichever is greater |
Model No |
AI-CO (Duct) |
Sensor |
Electrochemical type sensor (meets UL2034, EN50291, and EN54-31 requirements) |
Name of Manufacturer/Packer/Importer |
INSTRUKART HOLDING |
Warranty Duration |
12 Months |
Measure Range |
Options – 0–100 ppm, 0–250 ppm, 0–500 ppm |
Enclosure |
Duct mounting ABS plastic enclosure with duct mounting bracket |
Modbus |
Communication RS485 Modbus (optional) |
Relay |
1 No. relay output (CO/NO/NC) – optional |
