Ships within 90 days
Maximum Torque
Nameplate Speed
View
View
View
View
| Type of Product | AC Gearmotor |
| Maximum Torque | 500 in-lb |
| Phase | Single |
| Part No | 1LPX2 |
Type of Product |
AC Gearmotor |
Maximum Torque |
500 in-lb |
Phase |
Single |
Part No |
1LPX2 |
Frequency |
50 Hz 60 Hz |
Item Code |
1LPX2 |
Housing Material |
Die Cast Aluminum |
Standard |
C-UL Recognized UL Recognized |
Output Shaft Diameter |
3/4 inch |
Motor Type |
Permanent Split Capacitor |
Thermal Protection |
None |
Lubrication |
Grease Filled |
Gear Ratio |
80:1 |
Mount Type |
Any Position |
Operating Voltage |
115/230V AC |
Gear Material |
Hardened Steel |
Country of Origin |
United States |
Load Capacity |
400 ft-lb |
Output Shaft Length |
1-3/8 inch |
Bearing Type |
Ball and Needle on Case Ball on Motor |
Inverter Rated Watts |
Yes |
UNSPSC Code |
20101617 |
Rotation |
CW/CCW |
Seal Type |
Lip Type on Input and Output Shaft |
Mounting Orientation |
Any Angle |
Motor Enclosure |
Totally Enclosed Fan-Cooled |
Capacitor |
Yes |
Gear Type |
Helical (1st Stage) Spur (Subsequent Stages) |
Brake Type |
None |
Output shaft |
1 |
Mount Hole Center-to-Center Width |
3.63 inch |
Overall Width |
5.63 inch |
Depth |
1 inch |
Overall Height |
4.88 Inch |
Keyway Type |
0.18 sq in x 1 in |
Motor Insulation Class |
B |
Load Current |
2.05/1.05 A |
Ambient Temperature |
104 °F |
Length |
10 inch |
Keyway Width |
3/16 in |
Input Power |
0.2 hp |
Nameplate Speed |
20 RPM |
Shaft |
Parallel |
Finish Type |
Unpainted |
Depth (mm) |
25.4 mm |
Overall Height (mm) |
123.95 mm |
Overall Width (mm) |
143 mm |
Maximum Torque (Nm) |
56.5 Nm |
Load capacity (N) |
542.33 Nm |
