| Type of Product | AC Gearmotor |
| Maximum Torque | 320 in-lb |
| Phase | Single |
| Part No | 6Z816 |
Type of Product |
AC Gearmotor |
Maximum Torque |
320 in-lb |
Phase |
Single |
Part No |
6Z816 |
Frequency |
50 Hz 60 Hz |
Item Code |
6Z816 |
Housing Material |
Die Cast Aluminum |
Standard |
C-UL Recognized CE Certified UL Recognized |
Output Shaft Diameter |
5/8 inch |
Motor Type |
Permanent Split Capacitor |
Thermal Protection |
None |
Lubrication |
Permanent Heavy Duty Gear Oil |
Gear Ratio |
216:1 |
Mount Type |
Any Position |
Operating Voltage |
115/230V AC |
Gear Material |
Hardened Steel |
Country of Origin |
USA |
Load Capacity |
175 ft-lb |
Output Shaft Length |
1-1/2 inch |
Bearing Type |
Ball on Motor Heavy Duty Needle Roller and Thrust Balls on Case |
Inverter Rated Watts |
Yes |
UNSPSC Code |
26101602 |
Rotation |
CW/CCW |
Seal Type |
Lip Type on Input and Output Shaft |
Mounting Orientation |
Any Angle |
Motor Enclosure |
Totally Enclosed Fan-Cooled |
Capacitor |
Yes |
Gear Type |
Helical (1st Stage) Spur (Subsequent Stages) |
Brake Type |
None |
Output shaft |
1 |
Mount Hole Center-to-Center Width |
4 inch |
Overall Width |
6 inch |
Depth |
1/16 inch |
Overall Height |
5.13 Inch |
Mount Hole Center-to-Center Length |
1.5 inch |
Keyway Type |
Rounded |
Load Current |
2.0/1.0 A |
Ambient Temperature |
104 °F |
Length |
9.56 inch |
Keyway Width |
3/16 mm |
Input Power |
0.083 hp |
Nameplate Speed |
7.8 RPM |
Gear |
Class 9 |
Shaft |
Parallel |
Base to Centre |
3.5 inch |
Depth (mm) |
1.59 mm |
Overall Height (mm) |
130.3 mm |
Overall Width (mm) |
152.4 mm |
Maximum Torque (Nm) |
36.22 Nm |
Load capacity (N) |
237.27 Nm |
