Ships within 90 days
Maximum Torque
Nameplate Speed
View
View
View
View
| Type of Product | AC Gear Motor |
| Maximum Torque | 45 in-lb |
| Part No | M1135226.00 |
| Frequency | 50 Hz |
Type of Product |
AC Gear Motor |
Maximum Torque |
45 in-lb |
Part No |
M1135226.00 |
Frequency |
50 Hz |
Power |
1/4 HP |
Housing Material |
Aluminum |
Standard |
CSA Certified UL Recognized |
Output Shaft Diameter |
3/4 inch |
Motor Type |
Permanent Magnet DC |
Thermal Protection |
None |
Maximum Ambient Temperature |
40 °F |
Lubrication |
Permanent Heavy Fluid Gear Oil |
Gear Ratio |
10:1 |
Gear Material |
Hardened Steel |
Full Load Current (Amps) |
2 A |
Country of Origin |
USA |
Output Shaft Length |
1-5/8 inch |
Bearing Type |
Ball on Motor Heavy Duty Ball Needle Roller and Thrust Balls on Case |
UNSPSC Code |
26101603 |
Length Less Shaft |
11.31 inch |
Rotation |
CW/CCW |
Seal Type |
Heavy Duty Industrial |
Mounting Orientation |
Any Angle |
Motor Enclosure |
Totally Enclosed Nonventilated |
Shaft Orientation |
Parallel |
Gear Type |
Helical Spur |
Mount Hole Center-to-Center Width |
5 inch |
Overall Width |
6 inch |
Base to Center of Shaft |
4 inch |
Overall Height |
5.57 Inch |
Mount Hole Center-to-Center Length |
2.5 inch |
Overall Length |
12.94 inch |
Keyway Length |
1 inch |
Keyway Width |
3/16 inch |
Nameplate Speed |
250 RPM |
Overhung Load Capacity |
201 ft-lb |
Rated Voltage |
90 V DC |
Item No |
6ML59 |
Keyway Depth |
1 inch |
Length (mm) |
287.4 mm |
Overall Length (cm) |
32.87 cm |
Overall Height (mm) |
141.48 mm |
Overall Width (mm) |
152.4 mm |
Maximum Torque (Nm) |
5.09 Nm |
