| Type of Product | Bi-Directional TVS Diode |
| Dimension | 7.11 x 6.22 x 2.62 mm |
| Height | 2.62 mm |
| Width | 6.22 mm |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
Bi-Directional TVS Diode |
Dimension |
7.11 x 6.22 x 2.62 mm |
Height |
2.62 mm |
Width |
6.22 mm |
Country of Origin |
China |
Pack of |
10 Pcs |
Mounting Type |
Surface Mount |
Maximum Operating Temperature |
+150°C |
Minimum Operating Temperature |
-55°C |
Length |
7.11 mm |
Name of Manufacturer/Packer/Importer |
Diodes Zetex Semiconductors Limited |
Package Type |
SMC |
Pin Count |
2 |
Manufacturer Part Number |
SMCJ30CA-13-F |
Test Current |
1 mA |
Diode Configuration |
Single |
Number of Elements Per Chip |
1 |
Direction Type |
Bi-Directional |
Minimum Breakdown Voltage |
33.3V |
Maximum Clamping Voltage |
48.4V |
Peak Pulse Power Dissipation |
1500W |
Maximum Reverse Leakage Current |
5 µA |
Maximum Reverse Stand-off Voltage |
30V |
Maximum Peak Pulse Current |
31A |
