| Type of Product | LED Indicator Light |
| Mounting | Pole mounting |
| Model No | RETB-24-4-RYGB |
| Material | Globe: Polycarbonate resin |
Type of Product |
LED Indicator Light |
Mounting |
Pole mounting |
Model No |
RETB-24-4-RYGB |
Material |
Globe: Polycarbonate resin |
Light Source |
LED |
Country of Origin |
Japan |
Rated Voltage (V) |
DC 24 |
Protection Class |
IP64 (IP23 when using the included mounting bracket or optional mounting stand) |
Monotaro ID |
46264314 |
Power Consumption (W) |
Red, yellow 0.6/green, blue, white 1/buzzer 1 |
Interface |
NPN open collector |
Mass (Kg) |
0.7 |
Outer Diameter (Φmm) |
60 |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
Arrow & Harmony (Schneider Electric) |
Body Material |
ABS/Alloy resin |
Standard |
CE compliant product |
Cover Material |
Upper part: alloy resin |
No. of Tiers |
4 |
Lead Wire Length (mm) |
550 |
Buzzer Sound |
Continuous / intermittent sound switching |
Contact Capacity |
LED: Red/Yellow: 25mA or more above power supply voltage/Green/Blue/White: 40mA or more above power supply voltage, Buzzer: 100mA or more above power supply voltage |
Line Type |
Signal line/power line UL1007AWG22x6 |
Pole Material |
Aluminum (Φ22) |
Material (Foot Plate) |
Pole mounting: alloy resin |
