| Type of Product | LED Indicator Light |
| Mounting | Pole mounting / Standard L bracket |
| Model No | XVC6B45S-RYGB |
| Material | Globe: Polycarbonate resin |
Type of Product |
LED Indicator Light |
Mounting |
Pole mounting / Standard L bracket |
Model No |
XVC6B45S-RYGB |
Material |
Globe: Polycarbonate resin |
Light Source |
LED |
Country of Origin |
Indonesia |
Rated Voltage (V) |
AC/DC24 |
Protection Class |
IP54 (when mounted on horizontal surface), IP23 (when mounted on vertical surface) |
Monotaro ID |
46269905 |
Power Consumption (W) |
3.4 |
Interface |
NPN, PNP open collector |
Mass (Kg) |
0.9 |
Outer Diameter (Φmm) |
60 |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
Arrow & Harmony (Schneider Electric) |
Body Material |
ABS resin |
Standard |
CE compliant product, UL certified product, CSA certified product |
Cover Material |
Upper part: alloy resin |
No. of Tiers |
4 |
Lead Wire Length (mm) |
550 |
Buzzer Sound |
Continuous / intermittent sound switching |
Contact Capacity |
LED: Power supply voltage over 25mA, Buzzer: Power supply voltage over 100mA |
Flickering |
Speed: 60min <sup>-1</sup> |
Line Type |
Signal line, power line: CSA: 1 x 0.33mm² /AWG22 |
