| Type of Product | LED Indicator Light |
| Mounting | Direct attachment |
| Model No | XVC4B4K-RYGB |
| Material | Globe: Polycarbonate resin |
Type of Product |
LED Indicator Light |
Mounting |
Direct attachment |
Model No |
XVC4B4K-RYGB |
Material |
Globe: Polycarbonate resin |
Light Source |
LED |
Country of Origin |
Japan |
Rated Voltage (V) |
AC/DC24 |
Protection Class |
IP54 (when mounted on a horizontal surface) |
Monotaro ID |
46268959 |
Power Consumption (W) |
2.4 |
Interface |
NPN, PNP open collector |
Mass (Kg) |
0.2 |
Outer Diameter (Φmm) |
40 |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
Arrow & Harmony (Schneider Electric) |
Body Material |
ABS resin |
Standard |
CE compliant product, UL certified product, CSA |
Cover Material |
Upper part: alloy resin |
No. of Tiers |
4 |
Lead Wire Length (mm) |
600 |
Buzzer Sound |
None |
Contact Capacity |
LED: 25mA or more than power supply voltage, Buzzer: None |
Line Type |
Signal line, power line: CSA: 1 x 0.33mm² /AWG22 |
