| Type of Product | LED Indicator Light |
| Mounting | Wall |
| Model No | ROMLB-24-4-(RYGB) |
| Material | Upper cover: Alloy resin Glove: Polycarbonate resin Body: ABS/alloy resin |
Type of Product |
LED Indicator Light |
Mounting |
Wall |
Model No |
ROMLB-24-4-(RYGB) |
Material |
Upper cover: Alloy resin Glove: Polycarbonate resin Body: ABS/alloy resin |
Light Source |
LED |
Country of Origin |
Japan |
Rated Voltage (V) |
DC 24 |
Protection Class |
IP64 |
Monotaro ID |
75874084 |
Power Consumption (W) |
Red / Yellow: 0.6, Green / Blue / White: 0.5, Buzzer: 1 |
Interface |
NPN open collector |
Mass (Kg) |
0.2 |
Outer Diameter (Φmm) |
40 |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
Arrow & Harmony (Schneider Electric) |
Specifications |
With long body buzzer |
Standard |
CE compliant product. RoHS compliant product. |
Array |
Red / yellow / green / blue |
No. of Tiers |
1 |
Sound Pressure Level (dB) |
85 (1m forward) |
Tone |
buzzer |
Lead Wire Length (mm) |
750 |
Buzzer Sound |
Continuous sound |
Contact Capacity |
LED Red / Yellow: Power supply voltage over 25mA / LED Green / Blue / White: Power supply voltage over 20mA / Buzzer: Power supply voltage over 100mA |
Line Type |
Signal line / power line: UL1007AWG22 x 7 |
Operations |
Lighting |
