| Type of Product | LED Indicator Light |
| Mounting | Direct attachment |
| Model No | UTLAM-100W-3-RYG |
| Material | Globe: Polycarbonate resin |
Type of Product |
LED Indicator Light |
Mounting |
Direct attachment |
Model No |
UTLAM-100W-3-RYG |
Material |
Globe: Polycarbonate resin |
Light Source |
LED |
Country of Origin |
Japan |
Rated Voltage (V) |
AC110 |
Protection Class |
IP64 |
Monotaro ID |
46272897 |
Interface |
NPN open collector |
Outer Diameter (Φmm) |
100 |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
Arrow & Harmony (Schneider Electric) |
Body Material |
Alloy Resin |
Specifications |
Clear glove type |
Cover Material |
Upper part: alloy resin |
No. of Tiers |
3 |
Sound Pressure Level (dB) |
Up to 102 (1m forward) |
Lead Wire Length (mm) |
500 |
Buzzer Sound |
4 tones |
Flickering |
Speed: 130min <sup>-1</sup> Adjustable range: 40-180min <sup>-1</sup> |
Line Type |
VCT-F (Φ10) 13-core signal line UL1007AWG22 x 10, power line and earth line UL1007AWG18 x 3 |
