| Type | DR22 Series |
| Protection Class | IP65 (oil-proof type) |
| Model No | DR22F4M-M3W |
| Light Source | LED |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type |
DR22 Series |
Protection Class |
IP65 (oil-proof type) |
Model No |
DR22F4M-M3W |
Light Source |
LED |
Type of Product |
Flat Type Indicator Light |
Storage Temperature |
-40 to +80℃ |
Country of Origin |
Japan |
Relative Humidity |
Inside panel: 45-85% RH (at -5-+40°C) (with no icing or condensation) |
Shape |
Square |
Monotaro ID |
38569386 |
Rated Voltage (V) |
AC 220 |
Light Colour |
Milky white |
Rated Insulation Voltage (V) |
AC 600 |
Mounting Hole Diameter (Φmm) |
22.3/25.5 |
Name of Manufacturer/Packer/Importer |
Fuji Electric Co., Ltd. |
Operation Ambient Temperature (°C) |
-20-+50 (no freezing or condensation) |
Insulation Resistance (MOhm) |
Between live part and ground / between different polarity live parts: 100 or more (at 500 VDC megger) |
Import Country |
Direct Import from Japan |
Withstand voltage (V / min) |
(Between live part and ground) AC 2500 |
Terminal Screw |
M3.5 plus/minus screw with square washer (self-lifting type) |
Vibration |
Resonance test: double amplitude 0.1 mm, frequency 10-55 Hz/constant vibration endurance test: double amplitude 3.0 mm, frequency 16.7 Hz |
Rated Impulse Withstand Voltage (kV) |
6 |
Transformer |
Compliant |
Shock |
Durability: 500 |
Pollution Degree (Environment to Use) |
3 |
Method |
Transformer unit type |
