| Protection Class | IP65 |
| Lens Color | Red |
| Model No | AP6M266R |
| Light Source | LED |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Protection Class |
IP65 |
Lens Color |
Red |
Model No |
AP6M266R |
Light Source |
LED |
Type of Product |
AP Series LED small indicator Φ16 (round projection) |
Country of Origin |
Japan |
Shape |
Round |
Monotaro ID |
6916682 |
Mass (g) |
About 7.5 |
Rated Voltage (V) |
AC/DC6V |
Ambient Humidity to Use |
45 to 85% RH (no condensation) |
Light Colour |
Red |
Current Consumption (mA) |
33 |
Reverse voltage (V) |
100 |
Suitable Wire |
Φ1.0 or 0.75mm ² max |
Mounting Hole Diameter (Φmm) |
16.2 mm (0.2 - 0) |
Name of Manufacturer/Packer/Importer |
IDEC Corporation |
Operation Ambient Temperature (°C) |
-20 To 55°C (No Freezing) |
Import Country |
Direct Import from Japan |
Withstand voltage (V / min) |
Between live parts and non-current parts: 1000 |
Insulation_Resistance (MΩ) |
Between live parts and non-current parts: 100 MΩ or more (DC500V mega) |
Soldering Terminal |
Solder heat resistance of 260 ° C. Maximum (within 5 seconds) |
