| Model No | CW1L-A1P20Q4S |
| Type of Product | Flash Silhouette CW Series (Push-in terminal type) |
| Storage Temperature | -40 To 80°C (No Icing) |
| Country of Origin | Japan |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Model No |
CW1L-A1P20Q4S |
Type of Product |
Flash Silhouette CW Series (Push-in terminal type) |
Storage Temperature |
-40 To 80°C (No Icing) |
Country of Origin |
Japan |
Monotaro ID |
48060120 |
Name |
Illuminated Pushbutton Switch |
Terminal Shape |
Push-In Terminal |
Rated Insulation Voltage (V) |
300 V |
Contact Configuration |
2A |
Mounting Hole Diameter (Φmm) |
22.3 mm (0 - 0.4) |
Name of Manufacturer/Packer/Importer |
IDEC Corporation |
Operation Mechanism |
Round Flat |
Lamp Voltage (V) |
AC/DC24 V |
Operation Ambient Temperature (°C) |
-25 To 55°C (No Icing) |
Specifications |
Overvoltage Category: Ii Impulse Withstand Voltage (Kv): 2.5 Recommended Lock Nut Tightening Torque (N・M): 1.2 |
Vibration Resistance (Malfunction) |
5-55 Hz, Single Amplitude 0.5 mm |
Import Country |
Direct Import from Japan |
Pollution Degree (Environment to Use) |
3 |
Operation Type |
Alternate |
Insulation_Resistance (MΩ) |
100 MΩ or more (with DC500V mega) |
Rated Carrying Current (A) |
10A |
Contact Resistance |
50 mΩ or Less (Initial Value) |
Vibration Resistance (Destruction) |
30 Hz, 1.5 mm Single Amplitude |
Color of Operating Part |
Blue |
