| Type | Illuminated Pushbutton Switch |
| Protection Class | IP65 |
| Model No | LBW7L-A1T14WG |
| Type of Product | Flash silhouette LBW Series |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type |
Illuminated Pushbutton Switch |
Protection Class |
IP65 |
Model No |
LBW7L-A1T14WG |
Type of Product |
Flash silhouette LBW Series |
Storage Temperature |
-30-80°C (No Icing) |
Country of Origin |
Japan |
Mounting Hole (mm) |
⌀22.5 mm (0 - 0.2) |
Shape |
Square |
Monotaro ID |
48064950 |
Terminal Shape |
Soldering Tab Terminal |
Type of Illumination |
LED |
Contact Configuration |
1C |
Illuminated Colors |
Green |
Rated Operating Voltage (V) |
AC/DC24(LED) |
Name of Manufacturer/Packer/Importer |
IDEC Corporation |
Operation Mechanism |
Flat Type |
Operation Ambient Temperature (°C) |
-25 To 55°C (No Icing) |
Bezel Color |
Black |
Contact Material |
Gold Contacts |
Import Country |
Direct Import from Japan |
Withstand voltage (V / min) |
(Switch section) Between live section and earth: AC2000, Between opposite polarity terminals: AC2000, Between same polarity terminals: AC1000 (Illumination section) Between live section and earth: AC2000 |
Insulation_Resistance (MΩ) |
100 MΩ or more (DC500V mega) |
Contact Resistance |
50 mΩ or Less (Initial Value) |
Operations |
Alternate |
