| Type | Finished product |
| Protection Class | IP65 |
| Model No | HW2P-1Q4A |
| Type of Product | Hw Series Pilot Light Square Flat Type |
Type |
Finished product |
Protection Class |
IP65 |
Model No |
HW2P-1Q4A |
Type of Product |
Hw Series Pilot Light Square Flat Type |
Storage Temperature |
-40 to 80 (no icing) |
Country of Origin |
Japan |
Shape |
Square flat (signed type) |
Monotaro ID |
40163864 |
Name |
Pilot light |
Terminal Shape |
M3.5 screw terminal |
Light Colour |
Amber |
Illuminated Colors |
Amber |
Rated Operating Voltage (V) |
AC/DC24 |
Mounting Hole Diameter (Φmm) |
22.3(0 - +0.4) |
Name of Manufacturer/Packer/Importer |
IDEC Corporation |
Operation Ambient Temperature (°C) |
-25-50 (no icing) |
Vibration Resistance (Malfunction) |
5-55Hz, single amplitude 0.5mm |
Import Country |
Direct Import from Japan |
Insulation_Resistance (MΩ) |
100 or more (DC500V mega) |
Contact Resistance |
50 mΩ or Less (Initial Value) |
Vibration Resistance (Destruction) |
30Hz, 1.5mm single amplitude |
Impact Resistance (Malfunction) (m/s²) |
100 |
Impact Resistance (Durability) (m/s²) |
1000 |
Operating Ambient Humidity (% RH) |
45 to 85 (no condensation) |
Withstand voltage (V) |
Between live and non-live parts: AC2000 for 1 minute |
