| Type | Ap6M |
| Protection Class | IP65(IEC 60529) |
| Model No | AP6M166Y |
| Type of Product | AP Series LED type small indicator light |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type |
Ap6M |
Protection Class |
IP65(IEC 60529) |
Model No |
AP6M166Y |
Type of Product |
AP Series LED type small indicator light |
Input Type |
Direct type |
Country of Origin |
Japan |
Shape |
Round Flat |
Monotaro ID |
47982544 |
Mass (g) |
7.5 |
Terminal Shape |
Solder Terminal |
Current Consumption (mA) |
5 |
Suitable Wire |
Φ1.0 or 0.75mm ² max |
Illuminated Colors |
Yellow |
Rated Operating Voltage (V) |
AC/DC6 |
Name of Manufacturer/Packer/Importer |
IDEC Corporation |
Operation Ambient Temperature (°C) |
-20 To 55°C (But Do Not Freeze) |
Import Country |
Direct Import from Japan |
Withstand voltage (V / min) |
Between live parts and non-current parts: 1000 |
Insulation_Resistance (MΩ) |
100 MΩ or more (DC500V mega) |
Soldering Terminal |
Solder heat resistance: Maximum 350℃ (within 3 seconds) |
Storage Temperature Range |
-30-80°C (No Icing) |
Operating Voltage Range (V) |
AC/DC6±5% |
