| Type | With transformer |
| Protection Class | IP65 oil-proof type |
| Model No | A30ILT400OLE |
| Light Source | LED |
Type |
With transformer |
Protection Class |
IP65 oil-proof type |
Model No |
A30ILT400OLE |
Light Source |
LED |
Type of Product |
Pilot Light |
Country of Origin |
Japan |
Relative Humidity |
45 to 85% |
Shape |
Round |
Vibration Resistance |
10-55Hz, double amplitude 0.35mm |
Monotaro ID |
37856883 |
Rated Voltage (V) |
400/440 |
Light Colour |
Orange |
Rated Insulation Voltage (V) |
AC/DC600 |
Mounting Hole Diameter (Φmm) |
30.5(+0.5 to 0) |
Name of Manufacturer/Packer/Importer |
Maruyasu Electric Co., Ltd. |
Operation Ambient Temperature (°C) |
-20 to 55 |
Insulation Resistance (MOhm) |
100 or more (500 V) |
Import Country |
Direct Import from Japan |
RoHS Directive |
Correspondence |
Shock Resistance (m/s²) |
490 |
Installation Altitude (m) |
2000 or less |
Cold Resistance |
-40 to 70℃ |
Transformer Secondary Short Circuit |
No disconnection or ignition |
Strength |
(Terminal) 0.8Nm for 15 seconds |
Temperature Rise |
40K or less |
Heat Resistant Temperature (℃) |
-40 to 70 |
Rated Secondary Voltage (V) |
5.5 |
