| Type | Small indicator light |
| Protection Class | Ip40 |
| Model No | M2DA-90A1-00ER |
| Type of Product | Indicator Set |
Type |
Small indicator light |
Protection Class |
Ip40 |
Model No |
M2DA-90A1-00ER |
Type of Product |
Indicator Set |
Part No |
64-3377-11 |
Storage Temperature |
-25 to +65 ℃ (with no icing or condensation) |
Country of Origin |
JAPAN |
Terminal Type |
Solder Terminal |
Button Shape |
Square |
Monotaro ID |
39083922 |
Name |
Indicator Light |
Terminal Shape |
Solder Terminal |
Ambient Humidity to Use |
35 to 85%Rh |
Reverse voltage (V) |
Absolute maximum value: 4 |
Type of Illumination |
Led |
Illuminated Colors |
Red |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Body Shape |
Round body type (Φ8 mm) |
Illumination Section |
Square Red |
Power dissipation (mW) |
Absolute maximum value: 100 |
Forward current (mA) |
Standard value: 20, Absolute maximum value: 50 |
Forward voltage (V) |
Standard value: 1.7, Maximum value: 2.0 |
Operation Ambient Temperature (°C) |
-10 to +55 (with no icing or condensation) |
Import Country |
Direct Import from Japan |
