Ships within 25 days
View
View
View
View
| Type | Without cable |
| Country of Origin | Japan |
| Type of Product | Limit Switch |
| Allowable Operating Speed | 0.02 mm/s to 0.5 m/s |
Type |
Without cable |
Country of Origin |
Japan |
Type of Product |
Limit Switch |
Allowable Operating Speed |
0.02 mm/s to 0.5 m/s |
Protection Class |
IP67(IEC 60529, JIS C 0920) |
Contact Type |
C |
Actuator Type |
Short roller lever type |
Contact Material |
Standard load type: silver riveted contacts, Micro load type: gold plated riveted contacts |
Model No |
SL1-PV |
Monotaro ID |
7646695 |
Withstand Voltage |
Between contacts: AC1000V (50/60Hz, 1 minute, leakage current 1mA) |
Rated Frequency (Hz) |
45 to 65 and dc |
Short Circuit Protection Device |
M10A (IEC 60127) (TUV), Silver contact: Fast acting fuse 10A/Gold contact: Fast acting fuse 3A (CQC) |
Allowable Operation Frequency |
60 times / min or less |
Pollution Degree (Environment to Use) |
Pollution level 3 (EN60947-5-1) |
Rated Insulation Voltage (V) |
250 (The withstand voltage between each terminal and non-live metal parts is 2000V AC 45-65Hz, 5 seconds, leakage current 1mA) |
Operating Temperature Range |
0 to 120℃ |
Rated Impulse Withstand Voltage (kV) |
2500 |
Import Country |
Direct Import from Japan |
Terminal Shape |
M3 Binding Head Machine Screw with End Washer |
Name of Manufacturer/Packer/Importer |
Azbil Corporation |
Insulation Resistance (MOhm) |
Between terminals of the same polarity: 100 or more, Between each terminal and non-current-carrying metal part: 100 or more |
Specifications |
Switching overvoltage: Category II (IEC 60204-1), rated condition short circuit current: 1000A (power factor 0.5 to 0.7) |
Conformed Standard |
NECA C 4508/JIS C 8201-5-1 IEC 60947-5-1 |
Options |
High temperature and oil resistant type |
