| Country of Origin | Italy |
| Maximum Voltage | 400 V |
| Type of Product | Limit Switch |
| Length | 30.3 mm |
Country of Origin |
Italy |
Maximum Voltage |
400 V |
Type of Product |
Limit Switch |
Length |
30.3 mm |
Operating Force |
0.1 Nm |
Housing Material |
Glass Fibre Reinforced Thermoplastic |
Actuator Type |
Adjustable Roller Lever |
Depth |
30 mm |
Model No |
9026865 |
Mechanical Life |
15000000Operations |
IP Rating |
IP65 |
Configuration |
DPST |
Normal State Configuration |
NO/NC |
Voltage (Dc) |
250 V |
Action Type |
Snap ACtion |
Connection Type |
Cable |
Maximum Current |
10 A |
Orientation |
Vertical |
Maximum Operating Temperature |
+70°C |
Width |
170.5 mm |
Minimum Operating Temperature |
-25°C |
Name of Manufacturer/Packer/Importer |
RS Component |
