| Type of Product | Flash Memory |
| Height | 0.75 mm |
| Width | 8 mm |
| Country of Origin | United Kingdom |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
Flash Memory |
Height |
0.75 mm |
Width |
8 mm |
Country of Origin |
United Kingdom |
Name of Manufacturer/Packer/Importer |
Infineon |
Manufacturer Part Number |
S25FL128SAGNFI011 |
Memory Size |
128Mbit |
Series |
S25FL |
Product Code |
1242645 |
Organisation |
128Mx1 bit, 32Mx4 bit, 64Mx2 bit |
Maximum Operating Supply Voltage |
3.6 V |
Number of Bits per Word |
1, 2, 4 |
Dimension |
8x6x0.75 mm |
Interface Type |
SPI |
Number of Words |
128M, 32M, 64M |
Maximum Operating Temperature |
+85°C |
Maximum Random Access Time |
14.5 ns |
Minimum Operating Supply Voltage |
2.7 V |
Package Type |
WSON |
Mounting Type |
Surface Mount |
Minimum Operating Temperature |
-40°C |
Pin Count |
8 |
Cell Type |
NOR |
Block |
Sy mmetrical |
Length |
6 mm |
Automotive Standard |
AEC-Q100 |
