| Type of Product | Flash Memory |
| Height | 1.05 mm |
| Width | 18.5 mm |
| Country of Origin | United States |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
Flash Memory |
Height |
1.05 mm |
Width |
18.5 mm |
Country of Origin |
United States |
Name of Manufacturer/Packer/Importer |
Infineon |
Manufacturer Part Number |
S29GL128S90TFI010 |
Memory Size |
128Mbit |
Series |
S29GL |
Product Code |
1711483 |
Organisation |
8Mx16 bit |
Maximum Operating Supply Voltage |
3.6 V |
Number of Bits per Word |
16bit |
Dimension |
18.5x14.1x1.05 mm |
Interface Type |
CFI, Parallel |
Number of Words |
8M |
Maximum Operating Temperature |
+85°C |
Maximum Random Access Time |
90 ns |
Minimum Operating Supply Voltage |
2.7 V |
Package Type |
TSOP |
Mounting Type |
Surface Mount |
Minimum Operating Temperature |
-40°C |
Pin Count |
56 |
Cell Type |
NOR |
Block |
Sy mmetrical |
Length |
14.1 mm |
Automotive Standard |
AEC-Q100 |
