| Type of Product | Flash Memory |
| Height | 1.05 mm |
| Width | 18.5 mm |
| Country of Origin | Taiwan, Province Of China |
Type of Product |
Flash Memory |
Height |
1.05 mm |
Width |
18.5 mm |
Country of Origin |
Taiwan, Province Of China |
Name of Manufacturer/Packer/Importer |
Macronix |
Manufacturer Part Number |
MX29F040CTI-70G |
Memory Size |
4Mbit |
Series |
MX29F |
Product Code |
1703117 |
Organisation |
512Kx8 bit |
Maximum Operating Supply Voltage |
5.5 V |
Number of Bits per Word |
8bit |
Dimension |
18.5x8.1x1.05 mm |
Interface Type |
Parallel |
Number of Words |
512K |
Maximum Operating Temperature |
+85°C |
Maximum Random Access Time |
70 ns |
Minimum Operating Supply Voltage |
4.5 V |
Package Type |
TSOP |
Mounting Type |
Surface Mount |
Minimum Operating Temperature |
-40°C |
Pin Count |
32 |
Cell Type |
NOR |
Block |
Sy mmetrical |
Length |
8.1 mm |
