| Type of Product | PWM Controller |
| Frequency | 500 kHz |
| Output Current | 1 Amp |
| No. of Channels | 1 Channels |
Type of Product |
PWM Controller |
Frequency |
500 kHz |
Output Current |
1 Amp |
No. of Channels |
1 Channels |
Topology |
Boost, Flyback, SEPIC |
No. Of Pin |
16 Pins |
Country of Origin |
Philippines |
Name of Manufacturer/Packer/Importer |
FARNELL |
Ordering ID |
3559687 |
Manufacturer Part Number |
MAX15004DAUE/V+ |
Operating Temperature Max |
125°C |
MSL |
MSL 1 - Unlimited |
SVHC |
No SVHC (25-Jun-2025) |
Supply Voltage Max |
40 V |
Supply Voltage Min |
4.5 V |
Operating Temperature Min |
-40°C |
RoHS Compliant |
Yes 10 |
IC Case / Package |
TSSOP |
IC Mounting |
Surface Mount |
Controller IC Case Style |
TSSOP |
Maximum Switching Frequency |
500 kHz |
Control Mode |
Current Mode Control |
Minimum Switching Frequency |
15 kHz |
Maximum Duty Cycle |
50% |
Power Supply Controller Type |
Single Ended Controller |
Automotive Qualification Standard |
AEC-Q100 |
Qualification |
AEC-Q100 |
