| Type of Product | FC6A type programmable controller |
| Model No | FC6A-D16K4CEE |
| Type | Plus Cpu Module |
| Monotaro ID | 47999378 |
Type of Product |
FC6A type programmable controller |
Model No |
FC6A-D16K4CEE |
Type |
Plus Cpu Module |
Monotaro ID |
47999378 |
Maximum Power Consumption (w) |
2.88 (CPU module only) |
Accuracy |
±30 seconds/month 25℃ (clock) |
Mass (g) |
About 265 |
Rated Voltage (V) |
DC24 (action) |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Pulse Output |
Number of points: 4 points, Direction control: 1 pulse output mode: 4 axes (Q0 to Q7), 2 pulse output mode: 4 axes (Q0 to Q7) |
Name of Manufacturer/Packer/Importer |
IDEC Corporation |
Specifications |
Allowable Power Outage Time: 10 Ms Or Less (At Rated Power Supply Voltage)Power Supply Line: Ul1007 Awg24-16, Ul2464 Awg24-16, Ul1015 Awg20-16Grounding Line: Ul1007 Awg16Program Capacity: 800 Kb (Equivalent To 100,000 Steps)Number Of User Program Downloads: 1,000Number Of Expansion Modules That Can Be Added: 7 Modulesnumber Of Expansion Modules That Can Be Added Using Integrated Expansion Expansion Modules: 8 Modulesnumber Of Separate Expansion Modules That Can Be Added: 63 Modules (Maximum Of 1 Separate Master, Maximum Of 10 Separate Slaves)Shift Register: 256 Points |
Insulation_Resistance (MΩ) |
Between power supply terminals and FE terminals / Between transistor output terminals and FE terminals / Between power supply terminals and input terminals / Between power supply terminals and relay output terminals / Between input terminals and relay output terminals / Between input terminals and FE terminals / Between relay output terminals and FE terminals / Between power supply terminals and transistor output terminals / Between input terminals and transistor output terminals: 100 MΩ or more (DC 500V megger) |
Type of Terminal Fitting |
DIN rail or direct mounting |
Contents |
1 Pc |
