| Type of Product | Connector Plug |
| Model No | XS2G-D4S5 |
| Withstand Voltage | AC1500 (Leakage current at connector: 1mA or less) |
| Material | Contact/brass Fixtures/brass Contact block/PBT resin (UL94V-O) O-ring/rubber Cover/PBT resin (UL94V-O) Cap/PBT resin (UL94V-O) Cable clamp/PA resin (UL94V-O) Contact clamp/PBT resin (UL94V-O) Lock spring/LCP resin (UL94V-O) waterproof bushing/rubber ring/steel |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
Connector Plug |
Model No |
XS2G-D4S5 |
Withstand Voltage |
AC1500 (Leakage current at connector: 1mA or less) |
Material |
Contact/brass Fixtures/brass Contact block/PBT resin (UL94V-O) O-ring/rubber Cover/PBT resin (UL94V-O) Cap/PBT resin (UL94V-O) Cable clamp/PA resin (UL94V-O) Contact clamp/PBT resin (UL94V-O) Lock spring/LCP resin (UL94V-O) waterproof bushing/rubber ring/steel |
Type |
Waterproof Connector |
Rated Voltage (V) |
AC /DC 250 |
Monotaro ID |
39107013 |
Rated Current (A) |
3 |
No. of Pole |
4 poles |
Surface Treatment |
Contact/Ni base gold plating 0.4m Fixture/Ni plating |
Color |
Contact block / light gray |
Protection Class |
IP67(IEC529) |
Country of Origin |
JAPAN |
Operating Temperature Range |
-25 to 70 |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Power Supply |
For DC |
Category |
Adaptors Plugs & socket |
