| Type | BBWN-100 |
| Rated Current (A) | 75 |
| Type of Product | Circuit Breaker |
| No. of Pole | 3P3E |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type |
BBWN-100 |
Rated Current (A) |
75 |
Type of Product |
Circuit Breaker |
No. of Pole |
3P3E |
Rated Voltage |
AC 100/200 V only (AA) 25 kA |
Model No |
BBWN375 |
Frame |
100AF |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
Panasonic Corporation |
Display Type |
When phase is missing: Mechanical button |
Monotaro ID |
61364180 |
Import Country |
Direct Import from Japan |
Terminal Shape |
For crimp terminal |
External Dimensions (width x depth x height) (mm) |
75 x 130 x 68 (95 including handle) |
Mass (Kg) |
0.9 |
Operating Time |
Phase loss: within 0.5 |
Applicable crimp terminal |
(Nichifu) 14-8, 22-8 |
Quantity |
One |
Operation Ambient Temperature (°C) |
-10 to 60 |
voltage rating (V) |
Overvoltage: 130±5 |
Reverse Connection |
Impossible |
