| Rated Current (A) | 100 |
| Type of Product | Circuit Breaker |
| No. of Pole | 3P2E |
| Model No | BBQF31005 |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Rated Current (A) |
100 |
Type of Product |
Circuit Breaker |
No. of Pole |
3P2E |
Model No |
BBQF31005 |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
Panasonic Corporation |
Display Type |
(Overvoltage) Mechanical Display |
Monotaro ID |
38171472 |
Rated Breaking Capacity (kA) |
5 |
Frame (AF) |
100 |
Rated Voltage (V) |
AC100 / 200 only |
Import Country |
Direct Import from Japan |
Terminal Shape |
(Power Side) Dedicated Crimp Terminal |
Overcurrent Tripper Type |
Thermal / Electromagnetic |
Phase / Wire Type |
1Φ3W |
Terminal Screw |
(Power Supply Side) M8 |
Applicable crimp terminal |
38-8S (included) |
Tightening Torque (Nm) |
5.5-7.0 |
Specifications |
AA neutral wire with open-phase protection (3P2E), (abnormal voltage protection) 130 ± 5 V |
