| Type | NCD-30DS (rainproof type) |
| Rated Current (A) | 30 |
| Type of Product | Hand Switch Case Breaker |
| No. of Pole | 3P0E |
Type |
NCD-30DS (rainproof type) |
Rated Current (A) |
30 |
Type of Product |
Hand Switch Case Breaker |
No. of Pole |
3P0E |
Rated Voltage |
AC 250 V (rated short-time current 1kA 0.2 seconds) |
Model No |
BCD933071N |
Frame |
30 AF |
Features |
A Commercially available padlock can be attached (Φ8 mm) |
Material |
plastic case |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
Panasonic Corporation |
Monotaro ID |
61367865 |
Storage equipment |
Disconnector BBW9330 |
Import Country |
Direct Import from Japan |
Specifications |
Standard type, for both three-phase and single-phase use, for single exposed construction |
Quantity |
One |
Installation Location |
For outdoor use (rainproof type, IP43) |
Earth Terminal |
Can be installed as an option |
