| Rated Current (A) | 30 |
| Type of Product | Can Touch Breaker |
| No. of Pole | 2P1E |
| Model No | BKFE23031 |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Rated Current (A) |
30 |
Type of Product |
Can Touch Breaker |
No. of Pole |
2P1E |
Model No |
BKFE23031 |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
Panasonic Corporation |
Monotaro ID |
38181857 |
Rated Breaking Capacity (kA) |
5 |
Frame (AF) |
50 |
Rated Voltage (V) |
AC100 only |
Rated Sensitivity Current (mA) |
30 |
Import Country |
Direct Import from Japan |
Terminal Shape |
(Power Side) Crimp Terminal, (Load Side) Quick Connection Terminal |
Overcurrent Tripper Type |
Thermal / Electromagnetic |
Mass (Kg) |
0.15 |
Operating Time |
Within 0.1 Seconds |
Earth Leakage Indication |
Mechanical Button |
Suitable Terminal |
(Crimp Terminal) 2-5, 5.5-5, 8-5S (Quick Connection Terminal) Φ1.6, Φ2.0, Φ2.6 |
Phase / Wire Type |
1Φ2W (Single-Phase 2-Wire 100V) |
