| Type | BBWM-50S |
| Rated Current (A) | 32 |
| Type of Product | Motor Breaker |
| No. of Pole | 3P3E |
Type |
BBWM-50S |
Rated Current (A) |
32 |
Type of Product |
Motor Breaker |
No. of Pole |
3P3E |
Rated Voltage |
AC 200 V 10kA |
Model No |
BBWM3321S |
Frame |
50 AF |
Standard |
JIS agreement type |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
Panasonic Corporation |
Monotaro ID |
61366535 |
Connectable Stranded Wire (mm²) |
2 to 14 |
Import Country |
Direct Import from Japan |
Terminal Shape |
Full up terminal |
External Dimensions (width x depth x height) (mm) |
75 x 96 x 60 (75.6 including handle) |
Wire Diameter |
Φ1.6 to 2.6 mm |
Mass (Kg) |
0.4 |
Tightening Torque (Nm) |
2 to 2.5 |
Quantity |
One |
Method |
Overcurrent: Electromagnetic |
Reverse Connection |
Impossible |
DIN Rail Type |
Can be installed |
