| Type | BCWA-60 |
| Rated Current (A) | 50 |
| Type of Product | Circuit Breaker |
| No. of Pole | 2P2E |
Type |
BCWA-60 |
Rated Current (A) |
50 |
Type of Product |
Circuit Breaker |
No. of Pole |
2P2E |
Rated Voltage |
AC 100 V 2.5 kA, AC 200 V 2.5 kA |
Model No |
BCWA2501 |
Frame |
60 AF |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
Panasonic Corporation |
Monotaro ID |
61364645 |
Connectable Stranded Wire (mm²) |
2 to 14 |
Import Country |
Direct Import from Japan |
Terminal Shape |
Full up terminal |
External Dimensions (width x depth x height) (mm) |
47x96(106 including terminal cover)x52(67.6 including handle) |
Wire Diameter |
Φ1.6 to 2.6 mm |
Mass (Kg) |
0.3 |
Phase / Wire Type |
1Φ2 W |
Applicable crimp terminal |
(Nichifu) 14-5, CB22-5S |
Tightening Torque (Nm) |
2 to 2.5 |
Specifications |
For installation inside the box, with terminal cover |
Quantity |
One |
Method |
Electromagnetic |
Reverse Connection |
Possible |
