| Rated Current (A) | 20 |
| Type of Product | Can Touch Breaker |
| No. of Pole | 2P2E |
| Model No | BKF22032Z |
Rated Current (A) |
20 |
Type of Product |
Can Touch Breaker |
No. of Pole |
2P2E |
Model No |
BKF22032Z |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
Panasonic Corporation |
Monotaro ID |
38181683 |
Rated Breaking Capacity (kA) |
5(1Φ3W), 2.5(1Φ2W) |
Frame (AF) |
50 |
Rated Voltage (V) |
AC200 only |
Rated Sensitivity Current (mA) |
30 |
Import Country |
Direct Import from Japan |
Terminal Shape |
(Power Side) Crimp Terminal, (Load Side) Quick Connection Terminal |
Mass (Kg) |
0.17 |
Operating Time |
(Alarm) Within 0.1 Seconds |
Contact Configuration |
1C |
Earth Leakage Indication |
Red Led Display |
Contact Capacity |
AC125V: (Resistive load) 0.5A, (Inductive load) 0.5A AC250V: (Resistive load) 0.5A, (Inductive load) 0.5A DC30V: (Resistive load) 2A, (Inductive load) 2A |
Alarm Output |
Lead Wire Connection Method |
Type of Resetting |
(Alarm) Manual Reset (Push Button) |
Suitable Terminal |
(Crimp Terminal) 2-5, 5.5-5, 8-5S (Quick Connection Terminal) Φ1.6, Φ2.0, Φ2.6 |
