| Type of Product | Multi-MPPT String Inverter |
| Model No | SG125CX |
| Protection Degree | IP66 |
| Display | LED, Bluetooth+APP |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
Multi-MPPT String Inverter |
Model No |
SG125CX |
Protection Degree |
IP66 |
Display |
LED, Bluetooth+APP |
Weight |
87 Kg |
Voltage Range |
180 – 1000 V |
Maximum Input Power |
175 kW |
Phase |
3 Phase |
Dimension |
1020 x 795 x 360 mm |
Maximum Efficiency |
0.98499999999999999 |
Country of Origin |
India |
Name of Manufacturer/Packer/Importer |
Sungrow India (HQ) 304,3rd Floor, Picasso Centre, Golf Course Extension Road Sector-61, Gurugram Haryana-122102 |
Surge Protection |
DC Type I + II / A C Type II |
Input Voltage |
1100 V |
Rated Input Voltage |
600 V |
Ambient Temperature Range |
-30 to 60 ℃ |
Harmonics |
< 3 % (at rated power) |
Rated Output Current |
181.1 A |
Maximum output power |
125 kVA |
Voltage Range (AC) |
320 - 480V |
Cooling Method |
Smart forced air cooling |
Rated Output Power |
125 kW |
Operating Altitude |
4000 m (> 3000 m Derating) |
Mounting Method |
Wall-Mounting Bracket |
Topology |
Transformerless |
Grid Type |
Grid monitoring |
Humidity Range |
0 - 100 % |
Power Factor |
Adjustable 0.8 leading - 0.8 lagging |
Communication Function |
RS485 / Optional: WLAN, Ethernet |
AC Connection Type |
3-N-PE |
Power Consumption |
< 5W |
