| Type | Built-In Amplifier (M2 Mounting Type) (Limited Reflection Type) |
| Response Time | Operation / Reset: 1 ms or less |
| Shape | Side view |
| Output | NPN |
Type |
Built-In Amplifier (M2 Mounting Type) (Limited Reflection Type) |
Response Time |
Operation / Reset: 1 ms or less |
Shape |
Side view |
Output |
NPN |
Series |
E3T Series |
Type of Product |
Ultra-Compact, Ultra-Thin Photoelectric Sensor |
Power Supply Voltage |
DC12-24 ± 10% Ripple (pp) 10% or less |
Light Source |
Red |
Protection Class |
IEC standard IP67 |
Control Output |
Load power supply voltage 26.4VDC or less, load current 50mA or less (residual voltage 2V or less (load current 10 to 50mA), 1V or less (load current less than 10mA)), open collector output type |
Connection Type |
M12 connector relay |
Model No |
E3T-SL21-M1TJ 0.3M |
Cable Length (m) |
0.3 |
Case Material |
Polybutylene terephthalate |
Detection Method |
Limited reflection type |
Current Consumption (mA) |
20 or less |
Monotaro ID |
39051485 |
Head Shape |
Square |
Detection Distance (mm) |
5-30 (white paper 50 × 50) |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Withstand Voltage |
AC1000V 50/60Hz 1min |
Included Components |
Screw (M2 × 14), nut, spring washer, flat washer |
Detection Distance |
5 to 30 (white paper 50 x 50) |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
