Ships within 19 days
Model No
View
View
View
View
| Type | Built-In Amplifier (M2 Mounting Type) (Limited Reflection Type) |
| Output | NPN |
| Protection Circuit | Power / control output reverse connection protection, load short-circuit protection, mutual interference prevention function |
| Series | E3T Series |
Type |
Built-In Amplifier (M2 Mounting Type) (Limited Reflection Type) |
Output |
NPN |
Protection Circuit |
Power / control output reverse connection protection, load short-circuit protection, mutual interference prevention function |
Series |
E3T Series |
Type of Product |
Ultra-Compact, Ultra-Thin Photoelectric Sensor |
Power Supply Voltage |
DC 12-24 V ± 10% Ripple (pp) 10% or less |
Protection Class |
IEC standard IP67 |
Control Output |
Load power supply voltage 26.4 V DC or less, load current 50mA or less (residual voltage 2V or less (load current 10 to 50mA), 1V or less (load current less than 10mA)), open collector output type |
Connection Type |
M12 connector relay |
Model No |
E3T-SL11-M1TJ 0.3M |
Cable Length (m) |
0.3 |
Case Material |
Polybutylene terephthalate |
Detection Method |
Limited reflection type |
Current Consumption (mA) |
20 or less |
Ambient Humidity (% RH) |
During operation: 35-85 During storage: 35-95 (however, no condensation) |
Monotaro ID |
39051424 |
Head Shape |
Square |
Detection Distance (mm) |
5 to 15 (white paper 50 x 50) |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Operation Ambient Temperature (°C) |
Operating: -25 to 55, Storage: -40 to 70 (with no icing or condensation) |
Insulation Resistance (MOhm) |
20 Or More (At 500 VDC) |
