Ships within 19 days
Model No
View
View
View
View
| Type | Built-In Amplifier |
| Response Time | Operation / Reset: 1 ms or less |
| Operation Ambient Temperature | During operation: -25 to +55℃ When stored: -40 to +70℃ (However, do not freeze or condense) |
| Output | PNP Output |
Type |
Built-In Amplifier |
Response Time |
Operation / Reset: 1 ms or less |
Operation Ambient Temperature |
During operation: -25 to +55℃ When stored: -40 to +70℃ (However, do not freeze or condense) |
Output |
PNP Output |
Power Supply |
DC 12–24 ± 10%, Ripple (pp) 10% or less |
Series |
E3T Series |
Type of Product |
Ultra-Compact, Ultra-Thin Photoelectric Sensor (M3 mounting Type) |
Insulation Resistance |
20 MΩ or more (DC500V) |
Standard sensing Object |
Opaque Body with Φ2 mm or more |
Power Supply Voltage |
DC12-24V ± 10%, Ripple (PP) 10% or less |
Ambient Humidity |
Operating: 35 to 85% RH, Storage: 35 to 95 % RH (no condensation) |
Protection Class |
IEC60529 standard IP67 |
Cable Length |
2 m |
Current Consumption |
30 mA or less (Emitter: 10 mA or less, Receiver: 20 mA or less) |
Control Output |
Load Power Supply Voltage: 26.4VDC or less, Open Collector Output Type |
Connection Type |
Cord Drawer Type |
Load Current |
50mA or less (residual voltage 2V or less [load current 10 to 50mA], 1V or less [load current less than 10mA]) |
Model No |
E3T-ST14M 2M |
Case Material |
Polybutylene Terephthalate |
Detection Method |
Transparent Type |
Monotaro ID |
39051634 |
Head Shape |
Square |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Included Components |
Instruction Manual |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
