| Output | NPN |
| Series | E3Z Series |
| Type of Product | Photoelectric Sensor with Built-in Amplifier |
| Power Supply Voltage | DC12-24 ± 10% Ripple (pp) 10% or less |
Output |
NPN |
Series |
E3Z Series |
Type of Product |
Photoelectric Sensor with Built-in Amplifier |
Power Supply Voltage |
DC12-24 ± 10% Ripple (pp) 10% or less |
Light Source |
Infrared light emitting diode |
Protection Class |
IEC standard IP67 |
Control Output |
Load power supply voltage DC26.4V or less, load current 100mA or less (residual voltage load current less than 10mA: 1V or less, load current 10 to 100mA: 2V or less), open collector output type (NPN output) ON at light ON / ON at light blocking (Switch switching type) |
Connection Type |
M12 Smart Click Connector Relay Type |
Model No |
E3Z-T61-M1TJ 0.3M |
Cable Length (m) |
0.3 |
Mass (g) |
Approx. 75 (packed) |
Case Material |
Polybutylene terephthalate |
Detection Target |
Through-beam type (light emitter + light receiver) |
Standard Sensing Object (mm) |
Opaque body with Φ12 or more |
Detection Method |
Transmission Type (Emitter + Receiver) |
Monotaro ID |
39053962 |
Detection Distance (mm) |
15000 |
Country of Origin |
China |
Import Country |
Direct Import from Japan |
Withstand Voltage |
AC1000V 50/60 Hz 1min |
Included Components |
Instruction manual |
Set Contents |
Floodlight + receiver |
With or Without Indication Lamp |
Included |
Detection Distance |
15m |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Category |
Photoelectric Sensors |
