| Storage Temperature | -25 to 65℃ (no condensation or freezing) |
| Type of Product | Digital Temperature Controller Program Type |
| Type | E5EC-T |
| Input Type | Thermocouple, Resistance Temperature Detector, Sensor, Current, Voltage |
Storage Temperature |
-25 to 65℃ (no condensation or freezing) |
Type of Product |
Digital Temperature Controller Program Type |
Type |
E5EC-T |
Input Type |
Thermocouple, Resistance Temperature Detector, Sensor, Current, Voltage |
Model No |
E5EC-TCC4ASM-005 |
Control Output |
Current |
Character Height (mm) |
PV：18, Sv：11, MV：7.8 |
Monotaro ID |
66480487 |
Power Supply Voltage |
AC 100-240V (50/60Hz) |
No. Of Output |
4 |
Mass (g) |
Main unit: Approx. 210, Mounting adapter: Approx. 4 x 2 |
Applicable Standard |
EN 61010-1(IEC 61010-1), RCM |
Shape |
Din 48x96 |
Din Size |
DIN48x96 mm |
Terminal Shape |
Screw Terminal Block |
Country of Origin |
China |
Control |
ON/OFF control/PID control with auto tuning |
Import Country |
Direct Import from Japan |
Pattern Setting |
Digital setting with front keys |
Standard |
[Certification standards] cULus: UL 61010-1/CSA C22.2 No.61010-1, Korea Radio Regulations (Radio Act: KC mark) (some models only) |
Protection Class |
Front: IP66, Rear case: IP20, Terminal part: IP00 |
Operating Temperature Range |
-10 to 55℃ (no condensation or freezing) / 3-year warranty: -10 to 50℃ (no condensation or freezing) when installed as standard |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Specifications |
●Recommended fuse: T2A, AC 250 V time-lag low breaking capacity●Installation environment: Overvoltage category II, pollution degree 2 (EN/IEC/UL 61010-1)●[Effects of electromagnetic interference (according to EN 61326-1)] Thermocouple input (R, S, B, C/W, PLⅡ): (±1% of indicated value or ±10°C, whichever is greater) ±1 digit or less, other thermocouple input: (±1% of indicated value or ±4°C, whichever is greater) ±1 digit or less, platinum resistance thermometer input: (±1% of indicated value or ±2°C, whichever is greater) ±1 digit or less, analog input: ±1%FS ±1 digit or less, CT input: ±5%FS ±1 digit or less●Manual reset value: 0.0 to 100.0% (in 0.1% increments)●Port for setting tool: Top: USB-serial conversion cable Use the E58-CIFQ2 to connect to the USB port on the computer. Front: Use the USB-serial conversion cable E58-CIFQ2 + conversion cable E58-CIFQ2-E to connect to the USB port on the computer. |
Other functions |
Manual output, heating/cooling control, loop break alarm function, SP lamp, alarm function, heater break detection function (including SSR failure), 40% AT, 100% AT, operation amount limit, input digital filter, robust tuning, PV input correction, protection, square root calculation function, operation amount change rate limit, simple calculation, temperature status display function, input moving average, display brightness setting |
Remark |
Confirm Delivery Date Each Time |
